304 Stainless Steel Industry Mobile Vibrating Soil /Nickel Powder Screen With 800mm diameter
Product Introduction:
DY series powder vibro sieve is designed for accurate grading or sizing of wet and dry materials up to five fractions in one operation, low noise, high efficiency, need only 3-5 minutes to rapidly replace the screen, all closed structure. Used to sieve guanule, powder and liquid.
Main Features
1. High efficiency, refined design, duration, any powders, particle and mucilage are suitable for using.
2. Easy to replace the screen, simple operation and convenience washing.
3. Never jam the hole mesh work, no powder flying, filter size of the powder between 2 mesh and 500 mesh.
4. Automatically discharge the impurity and coarse materials, continuously operate.
5. Unique screen flame design, long duration of screen, only 3-5 minutes to replace the screen.
6. Small volume, move easily.
7. The highest layers of the screen are about 5 layers. But 3 layers are suggested.
Using Scope
1.Chemical industry: resin, coating, drug, industry, cosmetic, oil, herbal powder, ect.
2.Food industry: suger, gourmet powder, salt, fruit juice, starch, milk powder, food, soya-bean milk, egg powder, rice, soy, fish meal, pineapple juice, etc.
3.Metals,metallurgical mining: aluminum powder, lead powder, copper powder, ore, allay powder, electrode power, abrasive powder, refractory meterials, kaolin, lime, aluminum oxide, quartz sand, ect.
4.Other industries: abandoned oil, abandoned water, wasted-water dyeing, paper, chemicals, such as activated carbon.
Technical Parameters
| Model | Power(kw) | Valid Diameter of screen(mm) | Volume(mm) | Layers |
DY-600-1S
DY-600-2S
DY-600-3S | 0.55kw | 550mm | 800*800*680
800*800*780
800*800*880 | 1
2
3 |
|
DY-800-1S
DY-800-2S
DY-800-3S | 0.75 kw | 750mm | 900*900*780
900*900*930
900*900*1080 | 1
2
3 |
DY-1000-1S
DY-1000-2S
DY-1000-3S | 1.5 kw | 950mm | 1160*1160*880
1160*1160*1030
1160*1160*1180 | 1
2
3 |
DY-1200-1S
DY-1200-2S
DY-1200-3S | 1.75 kw | 1150 mm | 1360*1360*980
1360*1360*1160
1360*1360*1360 | 1
2
3 |
DY-1500-1S
DY-1500-2S
DY-1500-3S | 2.2 kw | 1450mm | 1850*1850*1130
1850*1850*1330
1850*1850*1550 | 1
2
3 |
DY-1800-1S
DY-1800-2S
DY-1800-3S | 3 kw | 1750mm | 2200*2200*1360
2200*2200*1460
2200*2200*1680 | 1
2
3 |
Our Company
Xinxiang Dayong Vibratory Equipment Co., Ltd. is a professional manufacturer of all kinds of mining equipment, with ISO9001-2008 certificated.
With 14 years manufacturing experience and scientific management and strong financial strength, our company has become a large and leading manufacturer in mineral processing and smelting equipment for nonferrous metals and nonmetals in Xinxiang area.
Among processing equipment, there includes feeding, crushing, sieving equipment. Moreover, our company offers full service from mining, prospecting, mineral processing experiment, project technical design, machinery and equipment installing to technical conduction and operators training.
FAQ
Please provide the following information for us.
1. material name.
2. the capacity you required (per hour)
3. Machine material. Please choose one:
a. Polypropylene PP plastic material
b. All stainless steel 304
c. All carbon steel
d. The contacting part is stainless steel, the other parts is carbon steel.
4. How many layers you need??
5. Please inform the voltage & frequency in your city.
